These are duty type rated motors developing high starting torque with low starting current. The motors are suitable for frequent starts/ stops and reversals. Also rapid acceleration is achieved by high pull out torque / rotor inertia ratio.
EMPD hoist duty motors are energy – efficient and perfect for heavy duty usage including cranes, lifts, weirs, sluices, auxiliary motors etc.
Applications
Chain Hoist
Rope Hoist
Trolley
Product Specifications
Motor type
Hoist & Crane Motors
Frame Size
63 to 250M
Power
0.15 to 15 kW
Polarity
2,4,6 & 8 / Dual Speed
Mounting
B3, B5, B14 & combinations
Voltage
415V ±10% or as required (VVVF)
Frequency
50Hz ±5% or as required(VVVF)
Protection
IP55 or superior on request
Ambient
Up to 2 Ton
Construction
Full Aluminium or Alu body with CI enclosure or Full cast iron
Enclosure
TEFC
Ins Class
Class F/ Class H insulation with temp rise limited to class B/Class F
